Scientific American, Vol. XXXIX. No. 6. [New Series.], August 10, 1878, by Various, is part of the HackerNoon Books Series. You can jump to any chapter in this book . A NEW DEEP SEA THERMOMETER. here A NEW DEEP SEA THERMOMETER. Perhaps some of our readers may have seen a description of a form of thermometer devised by MM. Negretti and Zambra for the purpose of ascertaining the temperature of the ocean at great depths. This consisted of a tube bent into the shape of a siphon, which when it had reached the desired depth was made, by means of an ingenious arrangement, to pour all the mercury found above a certain point near the reservoir into the second arm of the siphon. This second arm, which, like the other, was a capillary tube, carried a scale of divisions on which might be read the temperature of the depths to which the instrument had been lowered. This thermometer gave all the results that might have been expected. The ship Challenger during its polar expedition had on board a certain number of these instruments. The report of Capt. G. S. Nares made to the English Admiralty describes all the benefits that we may hope to reap from a serious study of the temperature of the ocean at different depths, and not the least of these are those that pertain to the fishery interest. Notwithstanding the good results given by this instrument, its inventors have endeavored to render it still more practical and more within the reach of all by diminishing the cost of construction, and increasing its compactness. represents the thermometer isolated from its case. It is an ordinary thermometer furnished at A with a little device that M. Negretti has already made use of in the construction of his larger instrument, and which allows the liquid to run from the reservoir into the capillary tube when the temperature rises, without letting it flow back when it lowers, if moreover the precaution has been taken to incline the tube slightly, reservoir upward. At B there is a bulge in the tube in which a certain quantity of mercury may lodge; this bulge is placed in such a way that the mercury resulting from the dilatation of the reservoir may come to it and continue its ascension in the capillary tube when the reservoir is down (the thermometer being vertical), but cannot get out when the reservoir is upward. Fig. 1 We should add that these thermometers are constructed so as to give the variations of temperature within determined limits. The small reservoir, B, is indispensable to the well working of the apparatus; for in seeking the temperature at a certain depth the instrument may, on being drawn up, pass through warmer strata, and it is necessary, therefore, to provide the reservoir with a means of diffusing the small quantity of mercury resulting from this excess of temperature. The tube has also a small bulge at its upper extremity at C. The thermometer is placed in a small wooden case having a double bottom throughout its length. In this double bottom are placed a certain number of lead balls that can run from one end of the case to the other, and of sufficient weight to render the instrument buoyant in sea water. To use the apparatus, one end of a cord is passed through a hole in the case under the reservoir of the thermometer, and the other end is tied to the sounding line at a certain distance from the lead ( ). While the line is descending the thermometer will remain reservoir downward ( ); but when it is again drawn up the thermometer case will take the position indicated in , and the column of mercury breaking at A will fall into the capillary tube, the divisions of which, as will be seen at , are reversed. Fig. 2 Fig. 2 Fig. 3 Fig. 1 As to the thermometer itself, it is important to protect it against the pressure which becomes so considerable at great depths; to do this the reservoir is surrounded by an envelope of thick glass about three quarters full of mercury. The mercury serves to transmit the temperature to the reservoir, and should the exterior envelope yield to the effects of pressure, the reservoir proper would not be affected, the mercury not exactly filling the annular part which surrounds it. New Inventions. George E. Palmer, of Cedar Rapids, Iowa, has patented an improved Ironing Board, on which the garments may be held in stretched state while being smoothed with the irons, and readily adjusted thereon to any required degree of tension by a simple attachment. William B. Rutherford and Joel T. Hawkins, of Rockdale, Texas, have patented an improved Bale Tie, which is formed of the plate provided with a longitudinal groove and cross ribs or loops, and having projections or keys to adapt it to receive and hold the notched ends of the bale band. An improvement in Composition Pavements has been patented by John C. Russell, of Kensington, Eng. This invention relates to the treatment of peat and spent tan for the manufacture of an improved product or material suitable for paving roads and other places and for roofing, etc. The most important steps in making the composition consist in drying bruised or finely ground peat or spent tan, heating the same to degree of 150° Fah., and adding sulphur and gas tar, gas pitch, and stearine pitch in the proportions specified, then kneading the mixture while heated and adding carbonate of lime and furnace slag. in vacuo Louis Blanck, of New York city, has patented an improved Safety Brake or attachment for locomotives and railroad cars, by which the entire train, either by a collision with another train or by contact with any obstruction, is first raised from the rails, and then moved in backward direction for the distance of a few feet, so that all danger of accident is avoided, and no other sensation than that of a slight rocking motion exerted. The attachment is constructed so as to admit of being worked by the engineer from the cab or the locomotive, or, if desired, from any car of the train. An improved Evaporating Pan had been patented by Andrew D. Martin, of Abbeville, La. This invention consists in a tapering sheet metal tank having transverse partitions and longitudinal tapering flues that extend through all of the partitions and terminate at the ends of the tank. Lloyd Arnold, of Galveston, Texas, has patented an improved Bale Tie, which is formed of a block of iron, with a space or opening running longitudinally through its breadth from one end nearly to the other, and having the alternate edges of the two plates thus formed notched, the notch of the lower plate being square and of a width equal to or a little greater than the bale band, and the notch of the upper plate being narrower at its bottom than the bale band, and with its sides inclined and beveled to an edge, to adapt it to receive and hold the bale band. An improved Tie for Letter Packages has been patented by John Mersellis, of Knowersville, N. Y. The object of this invention is to provide a tie by means of which letter packages may be quickly and securely fastened or tied. It consists in a plate apertured to receive one end of the string and also to receive the hook upon which the tie is hung when not in use, and having a button and clasp spring for engaging the string in the process of tying. Fred P. Hammond, of Aurora, Ill., has patented an improved Inking Pad, which consists in a novel arrangement of layers of cloth or felt, chamois skin, oiled silk, and printing roller composition, which enables a clean impression of the stamp to be made. The pad retains the desired rounded surface and proper degree of softness, and is easily manipulated when necessary to replenish the supply of ink. William J. Clark and Thomas W. Roberts, of Coffeeville, Miss., have patented an improved Trap for Catching Fish in streams, which will allow the fish to be conveniently taken out without taking up the trap. John W. Cooper, of Salem, Ind., is the inventor of an improved Alcohol Lamp for soldering and similar purposes; and it consists in a reservoir pivoted in a supporting frame, and provided with two wick tubes, and an extinguisher secured to a spring support, and capable of closing the larger wick tube when it is in a vertical position. It has an independent extinguisher for the smaller wick tube, and is provided with a novel device for projecting the wick from the larger tube as it is moved out of a vertical position. Benjamin Slater, of Attica, N. Y., has invented a simple and effective device for Renovating Feathers by the combined action of steam and hot air. It consists of a cylindrical receptacle, partly surrounded by a steam jacket, and having a hot air box, a perforated bottom, a cover or damper for the same, and an aperture in the top, to which is fitted a perforated cover and a close cover. An improved Blind Fastening has been patented by George Runton and John Runton, of Hoboken, N. J. This fastening is so constructed as to fasten the blind or shutter automatically when swung open, and in such a way as to prevent all rattling or shaking of the blind or shutter from the action of the wind. David R. Nichols, of Alexandria Bay, N. Y., has patented an improved Animal Trap, which is so constructed as to set itself after each animal has been caught, and leave no trace of the trapped animal to frighten away those that may come afterward. William A. Doherty, of Fall River, Mass., has patented an improved Loom Shuttle Attachment, by which the weaving of bad cloth is prevented, and in case any false shed is made by any irregularities in the warp, and that part of the shed carried lower than usual, the attachment is released and thrown over the spindle point, so as to render it impossible to draw out the filling from the shuttle, and thus break it and stop the loom. Jonas Bowman, of Somerset, O., has patented an improved Vehicle Spring, which permits of dispensing with side bars, thus taking less space to turn on, and by which the tilting and pitching motion usual with springs as heretofore constructed is avoided. Hiram Unger, of Germantown, O., is the inventor of an improved Gate Latch, which is so constructed that the gate cannot be opened accidentally by being lifted or by rebounding of the catch or latch. Madison Calhoun, of Ocate, Ter. of New Mex., has patented an improved Hame Fastening, which is not liable to become accidentally unfastened, and is easily and quickly fastened and unfastened, even with cold or gloved hands. The Downer well at Corry, Pa., is now down over 1,300 feet, and an oil bearing sand has been struck of about five feet thickness. About HackerNoon Book Series: We bring you the most important technical, scientific, and insightful public domain books. This book is part of the public domain. Various (2013). Scientific American, Vol. XXXIX. No. 6. [New Series.], August 10, 1878. Urbana, Illinois: Project Gutenberg. Retrieved https://www.gutenberg.org/cache/epub/19406/pg19406-images.html This eBook is for the use of anyone anywhere at no cost and with almost no restrictions whatsoever. You may copy it, give it away or re-use it under the terms of the Project Gutenberg License included with this eBook or online at , located at www.gutenberg.org https://www.gutenberg.org/policy/license.html
