Hi all, A few weeks ago, I faced a problem switching from a primary to a standby database. It was not the first time it occurred to me, so I decided to write about it. THE PROBLEM When executing the switchover, I faced an " ". ORA-03113: end-of-file on communication channel DGMGRL> switchover to stddb
Performing switchover NOW, please wait...
Error:
ORA-03113: end-of-file on communication channel
Process ID: 52627
Session ID: 1190 Serial number: 19862


Unable to switchover, primary database is still "pridb" Despite the DGMRL saying that the primary database was not switched, it was not the reality. I logged into the databases and checked their roles; as we can see, their roles were reversed. (SYS@pridb1,sid=10390)>select open_mode, database_role from gv$database;
OPEN_MODE                 DATABASE_ROLE
------------------------- ----------------------
READ ONLY WITH APPLY      PHYSICAL STANDBY
READ ONLY WITH APPLY      PHYSICAL STANDBY
READ ONLY WITH APPLY      PHYSICAL STANDBY


(SYS@stddb1,sid=11881)>select open_mode, database_role from gv$database;
OPEN_MODE            DATABASE_ROLE
-------------------- ----------------
READ WRITE           PRIMARY
READ WRITE           PRIMARY
READ WRITE           PRIMARY The DGMRL also did not update the databases' CRS information: --output clipped
[oracle@PRISERVER01 admin]$ srvctl confidatabase -db pridb
Database unique name: pridb
Database name: pridb
Start options: open
Stop options: immediate
Database role: PRIMARY

--output clipped
oracle@STDSERVER01:/home/oracle $> srvctl config database -db stddb
Database unique name: stddb
Database name: pridb
Start options: read only
Stop options: immediate
Database role: PHYSICAL_STANDBY FIXING THE PROBLEM Firstly I checked the current DGMGRL configuration and did take notes. DGMGRL> show configuration

Configuration - dg_conf

  Protection Mode: MaxPerformance
  Members:
  pridb - Primary database
    stddb - Physical standby database Secondly, I changed the databases' CRS configuration: srvctl stop database -db pridb -stopoption immediate
srvctl stop database -db stddb -stopoption immediate

srvctl modify database -db pridb -startoption "read only"
srvctl modify database -db pridb -role physical_standby
srvctl config database -db pridb

srvctl modify database -db stddb -startoption open
srvctl modify database -db stddb -role primary
srvctl config database -db stddb

srvctl start database -db pridb
srvctl start database -db stddb Lastly, I recreated the DGMGRL configuration: dgmgrl sys/password

DGMGRL>remove configuration
DGMGRL>create configuration dg_conf as primary database is stddb connect identifier is stddb;
DGMGRL>add database pridb as connect identifier is pridb maintained as physical;
DGMGRL>enable configuration

DGMGRL>show configuration

Configuration - dg_conf

  Protection Mode: MaxPerformance
  Members:
  stddb - Primary database
    pridb - Physical standby database

Fast-Start Failover: DISABLED

Configuration Status:
SUCCESS   (status updated 40 seconds ago)

DGMGRL> show database stddb

Database - stddb

  Role:               PRIMARY
  Intended State:     TRANSPORT-ON
  Instance(s):
    stddb1
    stddb2
    stddb3

Database Status:
SUCCESS


DGMGRL> show database pridb

Database - pridb

  Role:               PHYSICAL STANDBY
  Intended State:     APPLY-ON
  Transport Lag:      0 seconds (computed 1 second ago)
  Apply Lag:          0 seconds (computed 1 second ago)
  Average Apply Rate: 10.06 MByte/s
  Real Time Query:    OFF
  Instance(s):
    pridb1 (apply instance)
    pridb2
    pridb3

Database Status:
SUCCESS Those switchover errors occur to me more frequently than I would like, often due to processes preventing the database shutdown. So, before executing a switchover, I usually stop, then start the primary and standby databases, and this small procedure avoids so much pain during the night shifts. :-) That's all, folks, and I hope I have helped. Rodrigo Lima.
