Hello friends, The Oracle DBA occasionally needs to update some of the Oracle Clusterware network configurations. Today let's check how to update the private network part. The Environment Oracle RAC with 2 nodes: ol8-19-rac1 and ol8-19-rac2

Oracle Linux Server release 8.8

Grid Version
34318175;TOMCAT RELEASE UPDATE 19.0.0.0.0 (34318175)
34160635;OCW RELEASE UPDATE 19.16.0.0.0 (34160635)
34139601;ACFS RELEASE UPDATE 19.16.0.0.0 (34139601)
34133642;Database Release Update : 19.16.0.0.220719 (34133642)
33575402;DBWLM RELEASE UPDATE 19.0.0.0.0 (33575402)

DB Version
34086870;OJVM RELEASE UPDATE: 19.16.0.0.220719 (34086870)
34160635;OCW RELEASE UPDATE 19.16.0.0.0 (34160635)
34133642;Database Release Update : 19.16.0.0.220719 (34133642)

When you see <dbenv>, load the DB HOME variables.
When you see <gridenv>, load the GRID HOME variables.

IPs
# Public
192.168.56.161  ol8-19-rac1.localdomain  ol8-19-rac1
192.168.56.162  ol8-19-rac2.localdomain  ol8-19-rac2

# Virtual
192.168.56.163  ol8-19-rac1-vip.localdomain    ol8-19-rac1-vip
192.168.56.164  ol8-19-rac2-vip.localdomain    ol8-19-rac2-vip

# Private
10.1.2.161  ol8-19-rac1-priv.localdomain   ol8-19-rac1-priv
10.1.2.162  ol8-19-rac2-priv.localdomain   ol8-19-rac2-priv As the grid user, take a backup of profile.xml on all cluster nodes before proceeding. [oracle@ol8-19-rac1 ~]$ cp -p $ORACLE_HOME/gpnp/`hostname`/profiles/peer/profile.xml $ORACLE_HOME/gpnp/`hostname`/profiles/peer/profile.xml.bkp

[oracle@ol8-19-rac1 ~]$ ll $ORACLE_HOME/gpnp/`hostname`/profiles/peer/profile.xml.bkp

-rw-r--r--. 1 oracle oinstall 2171 May 27 20:09 /u01/app/19.0.0/grid/gpnp/ol8-19-rac1/profiles/peer/profile.xml.bkp Now, let’s check the Oracle CRS networks and the Linux networks. It’s possible to identify that Oracle is using the network as his private one. “eth2 10.1.2.0” [oracle@ol8-19-rac1 ~]$ oifcfg getif
eth1  192.168.56.0  global  public
eth2  10.1.2.0  global  cluster_interconnect,asm

[oracle@ol8-19-rac1 ~]$ ip -c -br a
lo               UNKNOWN        127.0.0.1/8 ::1/128
eth0             UP             10.0.2.15/24 fe80::a00:27ff:fe63:d73f/64
eth1             UP             192.168.56.161/24 192.168.56.163/24 192.168.56.166/24 192.168.56.165/24 fe80::a00:27ff:fe4f:b8aa/64
eth2             UP             10.1.2.161/24 169.254.1.211/19 fe80::a00:27ff:fe01:a7de/64
eth3             UP             10.1.3.161/24 fe80::a00:27ff:fef3:172b/64

[oracle@ol8-19-rac2 ~]$ ip -c -br a
lo               UNKNOWN        127.0.0.1/8 ::1/128
eth0             UP             10.0.2.15/24 fe80::a00:27ff:fe63:d73f/64
eth1             UP             192.168.56.162/24 192.168.56.164/24 192.168.56.167/24 fe80::a00:27ff:fe76:b954/64
eth2             UP             10.1.2.162/24 169.254.26.118/19 fe80::a00:27ff:fe7f:8663/64
eth3             UP             10.1.3.162/24 fe80::a00:27ff:fea8:d7c3/64 Let’s also check the ASM Listener configuration and take note. [oracle@ol8-19-rac1 ~]$ srvctl config listener -asmlistener
Name: ASMNET1LSNR_ASM
Type: ASM Listener
Owner: oracle
Subnet: 10.1.2.0
Home: <CRS home>
End points: TCP:1525
Listener is enabled.
Listener is individually enabled on nodes:
Listener is individually disabled on nodes:

[oracle@ol8-19-rac1 ~]$ srvctl status listener -l ASMNET1LSNR_ASM
Listener ASMNET1LSNR_ASM is enabled
Listener ASMNET1LSNR_ASM is running on node(s): ol8-19-rac2,ol8-19-rac1

[oracle@ol8-19-rac1 ~]$ srvctl config asm
ASM home: <CRS home>
Password file: +CRS/orapwASM
Backup of Password file: +CRS/orapwASM_backup
ASM listener: LISTENER
ASM instance count: 2
Cluster ASM listener: ASMNET1LSNR_ASM Firstly, let’s check if both nodes are able to reach the network we intend to use. [oracle@ol8-19-rac1 tmp]$ ping -c 3 10.1.3.161
PING 10.1.3.161 (10.1.3.161) 56(84) bytes of data.
64 bytes from 10.1.3.161: icmp_seq=1 ttl=64 time=0.010 ms
64 bytes from 10.1.3.161: icmp_seq=2 ttl=64 time=0.014 ms
64 bytes from 10.1.3.161: icmp_seq=3 ttl=64 time=0.018 ms

--- 10.1.3.161 ping statistics ---
3 packets transmitted, 3 received, 0% packet loss, time 2052ms
rtt min/avg/max/mdev = 0.010/0.014/0.018/0.003 ms

[oracle@ol8-19-rac1 tmp]$ ping -c 3 10.1.3.162
PING 10.1.3.162 (10.1.3.162) 56(84) bytes of data.
64 bytes from 10.1.3.162: icmp_seq=1 ttl=64 time=0.168 ms
64 bytes from 10.1.3.162: icmp_seq=2 ttl=64 time=0.151 ms
64 bytes from 10.1.3.162: icmp_seq=3 ttl=64 time=0.171 ms

--- 10.1.3.162 ping statistics ---
3 packets transmitted, 3 received, 0% packet loss, time 2068ms
rtt min/avg/max/mdev = 0.151/0.163/0.171/0.013 ms

[oracle@ol8-19-rac2 tmp]$ ping -c 3 10.1.3.161
PING 10.1.3.161 (10.1.3.161) 56(84) bytes of data.
64 bytes from 10.1.3.161: icmp_seq=1 ttl=64 time=0.153 ms
64 bytes from 10.1.3.161: icmp_seq=2 ttl=64 time=0.156 ms
64 bytes from 10.1.3.161: icmp_seq=3 ttl=64 time=0.176 ms

--- 10.1.3.161 ping statistics ---
3 packets transmitted, 3 received, 0% packet loss, time 2081ms
rtt min/avg/max/mdev = 0.153/0.161/0.176/0.017 ms

[oracle@ol8-19-rac2 tmp]$ ping -c 3 10.1.3.162
PING 10.1.3.162 (10.1.3.162) 56(84) bytes of data.
64 bytes from 10.1.3.162: icmp_seq=1 ttl=64 time=0.010 ms
64 bytes from 10.1.3.162: icmp_seq=2 ttl=64 time=0.025 ms
64 bytes from 10.1.3.162: icmp_seq=3 ttl=64 time=0.015 ms

--- 10.1.3.162 ping statistics ---
3 packets transmitted, 3 received, 0% packet loss, time 2037ms
rtt min/avg/max/mdev = 0.010/0.016/0.025/0.007 ms Since everything seems OK, now we will start changing the private network. We will change it from the subnet to . As the grid user, proceed as below in only one of the nodes. eth2:10.1.2.0 eth3:10.1.3.0 [oracle@ol8-19-rac1 ~]$ oifcfg setif -global eth3/10.1.3.0:cluster_interconnect,asm
[oracle@ol8-19-rac1 ~]$ srvctl add listener -asmlistener -l ASMNEWLSNR_ASM -subnet 10.1.3.0
[oracle@ol8-19-rac1 ~]$ srvctl update listener -listener ASMNET1LSNR_ASM -asm -remove -force

--The error below is expected, as we are only testing if the previous listener still exists.
[oracle@ol8-19-rac1 ~]$ lsnrctl stop ASMNET1LSNR_ASM

LSNRCTL for Linux: Version 19.0.0.0.0 - Production on 28-MAY-2023 07:55:09

Copyright (c) 1991, 2023, Oracle.  All rights reserved.

TNS-01101: Could not find listener name or service name ASMNET1LSNR_ASM Check if the ASM Listener was created correctly. [oracle@ol8-19-rac1 ~]$ srvctl config asm
ASM home: <CRS home>
Password file: +CRS/orapwASM
Backup of Password file: +CRS/orapwASM_backup
ASM listener: LISTENER
ASM instance count: 2
Cluster ASM listener: ASMNEWLSNR_ASM

[oracle@ol8-19-rac1 ~]$ srvctl config listener -asmlistener
Name: ASMNEWLSNR_ASM
Type: ASM Listener
Owner: oracle
Subnet: 10.1.3.0
Home: <CRS home>
End points: TCP:1526
Listener is enabled.
Listener is individually enabled on nodes:
Listener is individually disabled on nodes: In the 19c version, we also have one more resource to handle, the ASM Network. [oracle@ol8-19-rac1 ~]$ srvctl config asmnetwork
ASM network 1 exists
Subnet IPv4: 10.1.2.0//
Subnet IPv6:
Network is enabled
Network is individually enabled on nodes:
Network is individually disabled on nodes:

[oracle@ol8-19-rac1 ~]$ srvctl status asmnetwork
ASM network is running on ol8-19-rac2,ol8-19-rac1 As the root user, proceed as below. [root@ol8-19-rac1 scripts]# srvctl remove asmnetwork -netnum 1 -force
[root@ol8-19-rac1 scripts]# srvctl add asmnetwork -netnum 1 -subnet 10.1.3.0 Now let’s restart the entire cluster. [root@ol8-19-rac1 ~]# crsctl stop cluster -all -f
CRS-2673: Attempting to stop 'ora.crsd' on 'ol8-19-rac2'
CRS-2673: Attempting to stop 'ora.crsd' on 'ol8-19-rac1'
...
CRS-2673: Attempting to stop 'ora.cssd' on 'ol8-19-rac1'
CRS-2677: Stop of 'ora.cssd' on 'ol8-19-rac1' succeeded

[root@ol8-19-rac1 ~]# crsctl stop crs -f
CRS-2791: Starting shutdown of Oracle High Availability Services-managed resources on 'ol8-19-rac1'
...
CRS-2793: Shutdown of Oracle High Availability Services-managed resources on 'ol8-19-rac1' has completed
CRS-4133: Oracle High Availability Services has been stopped.

[root@ol8-19-rac2 ~]# crsctl stop crs -f
CRS-2791: Starting shutdown of Oracle High Availability Services-managed resources on 'ol8-19-rac2'
...
CRS-2793: Shutdown of Oracle High Availability Services-managed resources on 'ol8-19-rac2' has completed
CRS-4133: Oracle High Availability Services has been stopped.

[root@ol8-19-rac1 ~]# crsctl start crs
CRS-4123: Oracle High Availability Services has been started.

[root@ol8-19-rac2 ~]# crsctl start crs
CRS-4123: Oracle High Availability Services has been started. Check if everything is OK. [oracle@ol8-19-rac1 tmp]$ crsctl status res -t
--------------------------------------------------------------------------------
Name           Target  State        Server                   State details
--------------------------------------------------------------------------------
Local Resources
--------------------------------------------------------------------------------
ora.LISTENER.lsnr
               ONLINE  ONLINE       ol8-19-rac1              STABLE
               ONLINE  ONLINE       ol8-19-rac2              STABLE
ora.chad
               ONLINE  ONLINE       ol8-19-rac1              STABLE
               ONLINE  ONLINE       ol8-19-rac2              STABLE
ora.net1.network
               ONLINE  ONLINE       ol8-19-rac1              STABLE
               ONLINE  ONLINE       ol8-19-rac2              STABLE
ora.ons
               ONLINE  ONLINE       ol8-19-rac1              STABLE
               ONLINE  ONLINE       ol8-19-rac2              STABLE
ora.proxy_advm
               OFFLINE OFFLINE      ol8-19-rac1              STABLE
               OFFLINE OFFLINE      ol8-19-rac2              STABLE
--------------------------------------------------------------------------------
Cluster Resources
--------------------------------------------------------------------------------
ora.ASMNEWLSNR_ASM.lsnr(ora.asmgroup)
      1        ONLINE  ONLINE       ol8-19-rac1              STABLE
      2        ONLINE  ONLINE       ol8-19-rac2              STABLE
ora.CRS.dg(ora.asmgroup)
      1        ONLINE  ONLINE       ol8-19-rac1              STABLE
      2        ONLINE  ONLINE       ol8-19-rac2              STABLE
ora.DATA.dg(ora.asmgroup)
      1        ONLINE  ONLINE       ol8-19-rac1              STABLE
      2        ONLINE  ONLINE       ol8-19-rac2              STABLE
ora.LISTENER_SCAN1.lsnr
      1        ONLINE  ONLINE       ol8-19-rac2              STABLE
ora.LISTENER_SCAN2.lsnr
      1        ONLINE  ONLINE       ol8-19-rac1              STABLE
ora.LISTENER_SCAN3.lsnr
      1        ONLINE  ONLINE       ol8-19-rac1              STABLE
ora.RECO.dg(ora.asmgroup)
      1        ONLINE  ONLINE       ol8-19-rac1              STABLE
      2        ONLINE  ONLINE       ol8-19-rac2              STABLE
ora.asm(ora.asmgroup)
      1        ONLINE  ONLINE       ol8-19-rac1              Started,STABLE
      2        ONLINE  ONLINE       ol8-19-rac2              Started,STABLE
ora.asmnet1.asmnetwork(ora.asmgroup)
      1        ONLINE  ONLINE       ol8-19-rac1              STABLE
      2        OFFLINE OFFLINE                               STABLE
ora.cdbrac.db
      1        ONLINE  ONLINE       ol8-19-rac1              Open,HOME=/u01/app/o
                                                             racle/product/19.0.0
                                                             /dbhome_1,STABLE
      2        ONLINE  ONLINE       ol8-19-rac2              Open,HOME=/u01/app/o
                                                             racle/product/19.0.0
                                                             /dbhome_1,STABLE
ora.cvu
      1        ONLINE  ONLINE       ol8-19-rac1              STABLE
ora.ol8-19-rac1.vip
      1        ONLINE  ONLINE       ol8-19-rac1              STABLE
ora.ol8-19-rac2.vip
      1        ONLINE  ONLINE       ol8-19-rac2              STABLE
ora.qosmserver
      1        ONLINE  ONLINE       ol8-19-rac1              STABLE
ora.scan1.vip
      1        ONLINE  ONLINE       ol8-19-rac2              STABLE
ora.scan2.vip
      1        ONLINE  ONLINE       ol8-19-rac1              STABLE
ora.scan3.vip
      1        ONLINE  ONLINE       ol8-19-rac1              STABLE
-------------------------------------------------------------------------------- In my case, the ASM Network was not running on node 2, so I started it manually, and I will check in future reboots if I face the same issue again. [oracle@ol8-19-rac2 tmp]$ srvctl start asmnetwork

[oracle@ol8-19-rac2 tmp]$ srvctl status asmnetwork
ASM network is running on ol8-19-rac2,ol8-19-rac1 Since everything is running smoothly, let’s remove the previous network from the Oracle CRS. As the grid user, proceed as below. [oracle@ol8-19-rac1 tmp]$ oifcfg delif -global eth2/10.1.2.0

[oracle@ol8-19-rac1 tmp]$ oifcfg getif
eth1  192.168.56.0  global  public
eth3  10.1.3.0  global  cluster_interconnect,asm In the next article, I will explain how to update the IP from the other layers of the Oracle CRS. That’s it!

The code in this story is for educational purposes. The readers are solely responsible for whatever they build with it.
